LCD Display Optional Rack Mount Lifepo4 Battery 51.2V 100ah 200ah

Product Categories

ESS Lithium Battery [58]
Portable Lithium Battery Power Station [50]
Rackmount Lithium Battery [110]
Residential Battery Storage System [30]
All In One Inverter Battery [30]
Stackable Home Battery [28]
Lithium Battery Lead Acid Replacement [34]
Solar Energy Storage Battery System [10]
Wall Mounted Lifepo4 Battery [10]
Lifepo4 Battery Pack [14]
Rechargeable Lithium Battery Pack [14]

GUANGDONG XWELL TECHNOLOGY CO., LTD.

Contact Now

LCD Display Optional Rack Mount Lifepo4 Battery 51.2V 100ah 200ah

Name: LCD Display Optional Rack Mount Lifepo4 Battery 512V 100ah 200ah
Brand: XWELL
Price: 1 USD

Brand Name : XWELL

Model Number : XW-5120W-1

Certification : UN38.3,MSDS,UL,CB,BIS,PSE,GB4943.1 safety standard, CE, FCC, ROHS, battery UN38.3, MSDS, UL, CB, BIS, PSE

Place of Origin : China

MOQ : 1 pcs

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5000 pcs per month

Delivery Time : 7-10 working days

Packaging Details : Carton

Pack voltage : 48V to 51.2V

Pack type : LiFePO4 prismatic battery

Pack capacity : 50Ah 100Ah 200Ah

Pack energy : 2.56Kwh 5.12Kwh 10.24Kwh (Optional)

Discharge current : 50A

Max charge current : 50A

Discharge cut-off voltage : 42.5V

Display : LCD optional

Communication interface : RS485, RS232, CAN

Cycle life : >6000 Cycles(80%DOD)

Contact Now

Rackmount LiFePO4 Battery Power System 51.2V 100ah 200ah Lithium Ion Battery Pack

It' s long life character, highest energy and power density in the industry, fashionable design, easiness of installation and expansion, all reflects the real requirements of end users and strongest technical capability of Xwell's.Widely used in microgrid energy storage, photovoltaic energy storage, computer data ROM stand-by power, UPS and etc.

Features

1. A Grade lithium iron phosphate battery cell inside, superior safety,2000+heavy duty deep cycles lifetime.
2. Built-in smart BMS automatic protection for over-charge, over discharge, over current and over temperature.
3. Internal cell balancing.
4. Lighter weight and compact size: About 30% ~40% of the weight of a comparable lead acid battery.
5. IP65 waterproof.
6. Easy installation
7. Wider temperature range:-20℃~60℃.

Rackmount Lithium Battery Specification

Model	51.2V50Ah	51.2V100Ah	51.2V200Ah
Nominal voltage	51.2V
Nominal capacity (kwh)	2.56	5.12	10.24
Cell type	LiFePO4
Standard charge voltage	54.6V(adjustable)
Max charge current	50A
Discharge cut-off voltage	42.5V(adjustable)
Max discharge current	50A
Display	LCD(Optional)
Communication interface	CAN/RS485/RS232
Cycle life	>6000 Cycles (80%DOD)
Charge temperature range	0~45°C
Discharge temperature range	-20~60°C
Color	Black
Dimension (mm)	442x410x133 3U	442x410x177 4U	550x442x220 5U
Weight	About 35Kg	About 42Kg	About 84Kg
Installation method	Rack Mount

Cell Specification of Rackmount Lithium Battery
